3 Boot Heavy Type Log Car

78750

/Pcs

Available

Internal Hook Movement: Hydraulic.
Hook Drive System: Hydraulic.
Car Going And Coming: Hydraulic system with double rope.
Body: Steel Body.
Measurement System: Digital ( plc-touch) screen.
Lubrication System: Automatic (timed) lubrication.
Daily Log Cutting Capacity: 55 - 60 m³.
Hydraulic Unit Motor: 11 KW 1500 Rpm.
Boot Drive System: 7.5 KW Reducer Motor.
Rotation System: 3 KW Reducer Motor.
Boot Progress Speed: 310 mm/sec.
Car Progress Speed: 0-90 m/min.
Log Diameter Max: 1200 mm.
Max.Opening Of Hooks: 1000 mm.
Max. Opening Of Boots: 1200 mm.
Rail Width (Center To Center): 1520 mm.
Distance Between Hooks: 125 cm x 225 cm (Optional).
Dimensions: 240 cm x 570 cm x 180 cm (WxLxH).
Weight: 6000 Kg.

SKU: EWA-TR-OZE-287-V2-ÖE-ÜKTA-120
