usage advantages.
it consists of completely modular and bolted systems.
products that come in disassembled form are transported horizontally, so transportation and assembly are very easy.
it can be easily transported to the assembly area by passing through narrow areas in pieces.
it is more economical, durable and hygienic compared to welded or reinforced concrete water tanks.
prismatic water tanks do not form mold, fungus, bacteria and algae.
usage places:domestic water storage.
fire system water storage.
agricultural watering storage.
prismatic modular water tanks options:
aisi 304 stainless steel
aisi 316 stainless steel
galvanized steel
hot dip galvanized steel
specialty coated steel
Determining the option of Prismatic Water
Tank is really important due to purpose of use.
WATER TANK AND CONCRETE BASE PLACEMENT
MATTERS TO BE CONSIDERED DURING WATER TANK AND CONCRETE BASE PLACEMENT
When measuring the area where the water tank will be installed, it should be done from the closest places to each other.
Protrusions such as columns, beams, doors(heater, pillar, etc.) should not be considered during the measuring the place of concentre base CAUTIONS
1. THE FREE AREA AROUND THE ASSEMBLY PLACE OF WATER TANK MUST BE AT LEAST 50 CM
( TO PROVIDE BETTER ASSEMBLY ADVANTAGES)
2. CONCRETE BASE MUST BE MUST BE SMOOTH AND SMOOTH SURFACE IN C26 CALIBER
3. THE AREA BETWEEN ROOF OF THE WATER TANK AND THE CEILING MUST BE AT LEAST 40CM
( TO PROVIDE BETTER ASSEMBLY ADVANTAGES)
4 İNCLİNATİON ANGLE MUST BE ZERO.
OUR DIMENSIONS ARE IN MINIMETER TYPE
MODULAR PLASTIC CONCRETE
Where it is impossible to construct a concrete base or where the floor is covered, using a plastic base is another option.
The most important feature of Berrak Mechanical's modular water tanks is that the water tanks can be transported in parts and combined at the place of use.
It is also possible to increase the volume of the warehouse on-site or disassemble it and easily re-establish it in another place when needed.
You can create your own warehouse with the features and dimensions you want.
Modular Warehouse Accessories:
1- Warehouse Filling
2- Pump Suction
3- Level Indicator
4- Discharge Sleeve
5- Overflow Sleeve
6- Staircase
7- Side Manhole Cover
8- Upper Tank Cover
