Clip Dowel
143.55
/Box/QTY: 550 Pcs
Available
Clip Dowel is a strong and practical steel dowel in terms of its general structure. With its structure that can be used in general projects, the Clip Dowel product can be increased in strength depending on the quality of its raw material, which can handle high tonnages. You can also buy this product from our company, which is the only Clip Dowel manufacturer with a quality certificate in Turkey.
SKU: EWA-TR-MAY-105-2| Dimensions | Diameter | Quantity |
|---|---|---|
| M8X75 | 8 MM | 550 |
| M8X100 | 8 MM | 400 |
| M8X120 | 8 MM | 300 |
| M10X90 | 10 MM | 300 |
| M10X110 | 10 MM | 200 |
| M10X125 | 10 MM | 200 |
| M10X150 | 10 MM | 175 |
| M10X200 | 10 MM | 100 |
| M12X90 | 12 MM | 200 |
| M12X110 | 12 MM | 150 |
| M12X125 | 12 MM | 150 |
| M12X150 | 12 MM | 125 |
| M12X200 | 12 MM | 100 |
| M14X125 | 14 MM | 100 |
| M14X150 | 14 MM | 90 |
| M16X120 | 16 MM | 90 |
| M16X145 | 16 MM | 75 |
| M16X180 | 16 MM | 60 |
| M16X200 | 16 MM | 60 |
| M16X250 | 16 MM | 60 |
| M18X150 | 18 MM | - |
| M18X180 | 18 MM | - |
| M18X200 | 18 MM | - |
| M20X150 | 20 MM | 50 |
| M20X175 | 20 MM | 45 |
| M20X200 | 20 MM | 35 |
| M20X220 | 20 MM | 35 |
| M20X250 | 20 MM | 35 |
| M24X230 | 24 MM | 25 |
| M24X250 | 24 MM | 25 |
| M24X275 | 24 MM | 25 ‡uval |
Clip Dowels
Clip dowel is a strong and durable fastener that is frequently used in construction and assembly projects. It is especially preferred to fix heavy objects, shelves, and hanging devices to walls and ceilings.
What is a Clip Dowel?
A clip dowel is a fastener made of metal or plastic material, usually with a screw system inside. It is used to provide a strong connection between building materials. The clip dowel expands when the screw placed inside is tightened, providing a tight and solid hold between the connected surfaces.
Advantages of Clip Dowels:
- Strong and Durable Connection: Clip dowels provide a solid and strong connection between building materials, helping to securely fix heavy objects and structures during assembly processes.
- Wide Range of Application: Clip dowels can be used in concrete, wood, plasterboard, brick, and similar building materials. They offer flexible use in construction and assembly projects.
- Easy Use and Assembly: The installation of clip dowels is quite simple. First, a hole of suitable diameter is drilled on the surface to be connected. Then, the dowel is placed in the hole and tightened with a screw. This process is sufficient to provide a strong and solid connection.
- High Carrying Capacity: Clip dowels have a high carrying capacity, allowing heavy objects and structures to be mounted safely.
Clip Dowel Features:
The Clip Dowel is strong and practical due to its general structure. It is suitable for general projects and can carry high tonnages. The strength of the Clip Dowel product can be increased depending on the quality of its raw material. You can purchase this product from our company, which is the only quality-certified Clip Dowel manufacturer in Turkey. The Clip Dowel dimensions can be seen in our production line table below. It is a practical dowel that allows quick and easy installation. The concrete quality where the clip dowel will be mounted must be at least C20/25. The drill diameter and the dowel diameter are the same. When the nut is turned, the ring at the end of the dowel starts to open and holds in place by gripping the hole. It is zinc-coated against rust (5-8 Micron). Clip anchors are used in places with good concrete quality and have good resistance to suspended loads. They are suitable for fixing medium-class loads and are generally used in non-cracked concrete; some types are also suitable for cracked concrete.
Clip Anchor General Features:
You can achieve easy and fast installation with the wedge anchor. The concrete quality must be C20/25 to use the wedge anchor. The anchor diameter and drill diameter are the same. When you turn the nut, the clips at the end will open and hold onto the concrete. To resist rusting, it is plated with zinc.
